FRX100 VA M16 Housing for Sony RX100 III / IV / V / VA

The FRX100 VA M16 Housing was specially designed for the Sony Cyber-shot RX100 III, RX100 IV, RX100 V and RX100 VA digital cameras.

The FRX100 VA M16 Housing features an M16 port specially designed for the Fantasea Hybrid Vacuum Safety System (not included with the housing), which contains both a pre-dive vacuum check and an on-dive leak detector. The system allows confirming the watertight seal of the housing prior to the dive using the vacuum system and monitoring the housing seal during the dive using the moisture detector.

IMPORTANT NOTICE

Housing includes moisture detector and alarm only. Vacuum system isn't included with this housing model. It can be separately ordered and installed inside the housing. For a housing that includes an installed vacuum system, see the FRX100 VA Vacuum Housing (#1511).
The M16 port featured on this housing was designed to accommodate the Fantasea Hybrid Vacuum Safety System only. Other accessories cannot be installed using this port.

The FRX100 VA M16 Housing is manufactured to the highest professional standards of function, style and durability. It is depth rated to 60m/200 feet and is fully functional with ergonomically designed and labeled controls. The Fantasea FRX100 VA M16 Housing is the ultimate waterproof home for the Sony RX100 III, RX100 IV, RX100 V and RX100 VA cameras.

The FRX100 VA M16 Housing is ideal for outdoor and underwater photography. Underwater photographers can dive or snorkel and capture all the excitement of this fascinating world, while outdoor photographers also have the option of capturing the action of activities such as white water paddle sports, sailing, boating, surfing, fishing, hunting, backpacking and camping.

The FRX100 VA M16 Housing is shock resistant and protects the camera from water, sand, dust, frost and other damaging elements.

The FRX100 VA M16 Housing was designed to be compatible with a complete accessory system, enabling photographers to enhance the quality of their images.

Features Highlights:

M16 port for optional Vacuum Safety Systems*
Moisture detector and alarm
Depth rated to 60m/200 feet
Ergonomic design
Made from durable injection molded Polycarbonate
Full access to all essential camera controls & functions with clearly marked controls
Shock resistant
Double O-ring seal
Special mount for lighting accessories
Removable double fiber optic cable connection
Removable flash diffuser
Easy and secure installation of camera
Removable anti-glare hood for the LCD screen
Port Cover
Dedicated video control button for easy video filming in any shooting mode
Compatible with a wide range of underwater photo accessories

* Vacuum system is not included with this housing

Tables & Charts

Accessories Chart for Compact Housing

Accessories Table for Compact Housing

Wet Conversion Lenses Compatibility Table

Specifications

Weight (with camera on land): 900g
Weight (without camera on land): 600g
Dimensions (without accessories): 15.5 x 14.5 x 12 cm \ 6.25 x 5.75 x 4.75 inch (W x D x H)
Manufacturer's warranty included

Video

RX100III, RX100IV, RX100V, RX100VA, RX1003, RX100MK3, RX1004, RX100Mk4, RX1005, RX100Mk5, RX1005A, RX100Mk5A, RX100

About the RX100VA

The Sony Cyber-shot DSC-RX100VA

20.1MP 1" Exmor RS BSI CMOS Sensor BIONZ X Image Processor&Front-End LSI
Internal UHD 4K Video&S-Log2 Gamma
Zeiss Vario-Sonnar T* f/1.8-2.8 Lens
24-70mm (35mm Equivalent)
Fast Hybrid AF System with 315 Points
HFR Mode for Full HD Video up to 960 fps
0.39" 2.36m-Dot OLED Pop-Up EVF
3.0" 1.23m-Dot 180ø Tilting LCD
ISO 12800 and 24 fps Continuous Shooting

Taking an amazing pocket-sized series and further improving it, the Cyber-shot DSC-RX100 V Digital Camera from Sony takes the compact RX100 line up a notch by adding a Fast Hybrid AF system with 315 focal-plane phase-detection points. Incorporating a proven and reliable 20.1MP 1" Exmor RS BSI CMOS sensor, the RX100 V is able to create highly detailed images at sensitivities up to ISO 12800 with ease. Also, combining this sensor's speed and power with the BIONZ X processor and a newly developed front-end LSI, users can enjoy even faster performance, including continuous shooting of up to 24 fps with a buffer up to 148 JPEG frames, improved High Frame Rate recording times, and fast continuous AF with stills and while recording UHD 4K video.

The hallmark features are the advanced AF system which can now lock on in just 0.05 seconds and operate during the camera's maximum continuous shooting speed of 24 fps. The High Frame Rate mode, which can reach an incredible 960 fps can now record for twice as long. Other improvements made to the RX100 V include the addition of new functions and modes, such as a Gamma Display Assist which provides a more contrasty image while using a flat S-Log2 gamma and a built-in Photo Capture mode for pulling 8.29MP stills from your movies.

The front of the camera offers a familiar Zeiss Vario-Sonnar T* lens equivalent to 24-70mm and with a fast f/1.8-2.8 maximum aperture. This lens provides outstanding versatility for working in a wide range of conditions. In terms of design, the RX100 V retains the clean, versatile construction as its predecessors, including a lens control ring, built-in ND filter, and a variety of customizable buttons. For monitoring, this camera offers both a pop-up 0.39" 2.36m-dot OLED Tru-Finder EVF and a 3.0" 1.23m-dot LCD which can tilt upwards 180ø for selfies as well as downward 45ø for low-angle shooting. It also has built-in Wi-Fi with NFC for connecting to a smartphone.

Utilizing an advanced stacked structure with an integrated DRAM chip, the 20.1MP 1" Exmor RS CMOS sensor of the RX100 V is able to deliver outstanding image quality at up to ISO 12800 with incredibly fast performance. This sensor stacks the pixel area, a high-speed signal processing circuit, and memory in order to increase data throughput by over five times and deliver features such as 40x super slow motion, an Anti-Distortion shutter, UHD 4K video, and more. This is also the first 1" sensor to have focal-plane phase-detection AF points for faster, more precise focusing.

This sensor is paired with the BIONZ X image processor and a newly developed front-end LSI that dramatically improves the speed and throughput of the entire imaging system, enabling continuous shooting with AF/AE at up to 24 fps. An expanded buffer makes continuous shooting possible for longer bursts, up to 148 JPEGs or 71 raw files. The front-end LSI is also able to improve overall quality of the images, especially at higher sensitivities. Additionally, another advantage of this setup is raw output which provides outstanding color fidelity and image quality.

Specifications

Pixels ... Actual: 21.0 Megapixel
Effective: 20.1 Megapixel
Sensor ... 1" (13.2 x 8.8 mm) CMOS
File Formats ... Still Images: JPEG, RAW
Movies: AVCHD Ver. 2.0, MP4, XAVC S
Audio: AAC LC, AC3, Dolby Digital 2ch, Linear PCM (Stereo)
Max Resolution ... 20 MP: 5472 x 3648
Aspect Ratio ... 1:1, 3:2, 4:3, 16:9
Image Stabilization ... Optical
Color Spaces ... sRGB, Adobe RGB
Optics
Lens ... Carl Zeiss Vario-Sonnar, 10 elements in 9 groups
9 Aspherical
EFL: 8.8-25.7mm (35 mm equivalent: 24-70mm)
Aperture: f/1.8 (W) - 2.8 (T)
Zoom ... Optical: 2.9x
Clear Image Zoom: 5.8x
Digital: 11x
Focus Range ... Wide: 1.97" (5 cm) - Infinity
Telephoto: 11.81" (30 cm) - Infinity
Exposure Control
ISO Sensitivity ... Auto, 125-12800 (Extended Mode: 80-12800)
Shutter ... Type: Mechanical
Speed: 4 - 1/2000 second in Auto Mode
Type: Mechanical
Speed: 30 - 1/2000 second in Program Mode
Type: Mechanical
Speed: 30 - 1/2000 second in Manual Mode
30 - 1/2000 second in Aperture Priority Mode
Type: Mechanical
Speed: 30 - 1/2000 second in Shutter Priority Mode
Type: Electronic
Speed: 4 - 1/32000 second in Auto Mode
Type: Electronic
Speed: 30 - 1/32000 second in Bulb Mode
Type: Electronic
Speed: 30 - 1/32000 second in Program Mode
Type: Electronic
Speed: 30 - 1/32000 second in Aperture Priority Mode
Type: Electronic
Speed: 30 - 1/32000 second in Shutter Priority Mode
Exposure Metering ... Center-weighted, Multi, Spot
Exposure Modes ... Modes: Aperture Priority, Intelligent Auto, Manual, Memory Recall, Movie, Panorama Shot, Programmed Auto, Scene Selection, Shutter Priority, Superior Auto
Shooting Modes ... Anti-motion Blur
Fireworks
Gourmet
Handheld Twilight
High Sensitivity
Landscape
Macro
Night Portrait
Night Scene
Pet Mode
Portrait
Sports
Sunset
White Balance Modes ... Auto, Cloudy, Color Temperature Filter, Custom, Daylight, Flash, Fluorescent (Cool White), Fluorescent (Day White), Fluorescent (Daylight), Fluorescent (Warm White), Incandescent, Shade
Continuous Shooting ... Up to 24 fps at 20.1 MP for up to 148 frames in JPEG format
Up to 24 fps at 20.1 MP for up to 71 frames in raw format
Self Timer ... 10 Sec, 5 Sec, 2 Sec
Remote Control ... RM-VPR1 (Optional)
Flash
Flash Modes ... Auto
Flash On
Off
Rear Sync
Red-eye Reduction
Slow Sync
Built-in Flash ... Yes
Maximum Effective Flash Range ... Wide: 1.31 - 33.46' (0.4 - 10.2 m)
Telephoto: 1.31 - 21.33' (0.4 - 6.5 m)
External Flash Connection ... None
Memory
Memory Card Type ... Memory Stick Duo
Memory Stick Pro Duo
Memory Stick PRO Duo (High Speed)
Memory Stick PRO HG-Duo
SD
SDHC
SDXC
Recording
Video Recording ... Yes, NTSC/PAL
Resolution ... 3840 x 2160p: 30 fps, 25 fps, 24 fps
1920 x 1080p: 60 fps, 50 fps, 30 fps, 25 fps, 24 fps
1920 x 1080i: 60 fps, 50 fps
1280 x 720p: 30 fps, 25 fps
1920 x 1080p: 240 fps, 480 fps, 960 fps
1824 x 1026p: 240 fps, 480 fps, 960 fps
1676 x 566p: 240 fps, 480 fps, 960 fps
1920 x 1080p: 250 fps, 500 fps, 1000 fps
1824 x 1026p: 250 fps, 500 fps, 1000 fps
1676 x 566p: 250 fps, 500 fps, 1000 fps
Video
Video Clip Length ... Up to 29 Min
Audio Recording ... Built-in Mic: With Video, Stereo
Viewfinder/Display
Viewfinder Type ... Electronic
Diopter Adjustment ... - 4 to +3 m
Viewfinder Coverage ... 100%
Screen ... 3.0" LCD Rear Screen Tilt (1,228,800 pixels)
Connectivity/Syst
